Product Description

About

The BougeRV 300 Watt 12V/24V Rigid Bifacial 12BB Mono Solar Panel is designed for off-grid living and home backup, offering 23% efficiency through 12BB cell technology with 12 busbars for energy output, even in low light. Built with monocrystalline cells, it is designed to provide power for RVs, boats, cabins, and other off-grid applications.

The 12BB cell design increases the cell receiving surface with a thinner ribbon that reduces the covered area by 22%, contributing to a longer service life. The panel can charge a 12V battery directly, or be wired in series with other panels to charge a 24V or 48V battery. As a bifacial panel, it can absorb sunlight regardless of the sun's position without constant adjustment; a tilt mount bracket is recommended for optimum installation.

The panel is built with Class A solar cells that pass strict EL testing for no visible defects or microcracks, and ships in a package with protective strips, L-brackets, and thick foam padding designed to help it arrive undamaged.

Features

The 12BB cell design achieves up to a 23% conversion rate and increases the cell receiving surface with a thinner ribbon that reduces covered area by 22%, contributing to a longer service life; it also allows the panel to charge a 12V battery directly or be wired in series with other panels to charge a 24V or 48V battery. As a bifacial panel, it can absorb sunlight regardless of the sun's direction without constant adjustment, and a tilt mount bracket is recommended for optimum installation. The panel is made of Class A solar cells with no visible defects or microcracks, verified through strict EL testing. Packaging includes a protective strip on all sides, L-brackets on all corners, and an extra thick foam pad on the back for shipping protection. An IP67-rated waterproof junction box with pre-installed diodes and a pair of pre-attached 3ft solar cables, along with pre-drilled holes on the back of the panel, allow for installation without heavy tools.

Specifications

  • SKU: ISE239
  • Maximum Power (W): 300±5% W
  • Open Circuit Voltage Voc (V): 40.7±5% V
  • Max Power Voltage Vmp (V): 34.8±5% V
  • Max Power Current Imp (A): 8.62±5% A
  • Short Circuit Current Isc (A): 9.64±5% A
  • Solar Cells Efficiency: 23%
  • Product Dimension (IN): 64.57x34.65x1.38 inches
  • Net Weight: 35.31 lb
  • Application Class: Class A
  • Max Static Load (front): 2400 Pa
  • Max Static Load (back): 2400 Pa
  • Series Fuse Rating: 15A
  • Product Type: Solar Panel

Warranty

10 years product warranty and 25-years power warranty
